Product Details
The Milani Progressive Single Mixer is a single hand mixer that utilises innovative progressive cartridge technology. This product allows you to simultaneously control the water flow and temperature in a simple twist of the dial. You rotate in a clockwise motion for low-pressure cold up to high water flow. Once the dial is turned halfway, warm water is introduced at full pressure.
The innovative design allows you to replace your handles at any time after installation for a different design or finish. This makes it suitable for both new installation and retrospective tapware upgrades.
Also, whether you want your mixer positioned to the side of your tapware or vertically, due to its unique design, the mixer’s wall placement possibilities are open to you.
Please Note:
– This wall progressive mixer is not thermostatic. Your plumber may be able to install a Thermostatic Mixing Valve (TMV) to enable this functionality. The TMV is installed after the hot supply, providing you with a blended hot temperature that will help prevent scalding if there is a sudden drop in cold supply to the mixer. Installing a TMV is a common installation method in the UK.
Please head to the ‘Downloads’ tab and under ‘Product Documents’ refer to our TMV Placement document for more information and placement examples.
If you are looking for a thermostatic alternative, please refer to our Eden Thermostatic Shower Rail Set here
Features:
– PSLT (PrimeShield Lacquer Technology)
– Precise temperature and pressure handling
– Ceramic Cartridge
– Solid Brass Construction
Dimensions:
– 54mm Diameter
– 62mm Backplate Diameter
Browse our complete range of white taps.
Shop Other Colour Options
Shop Other Colour Options
Product Info
Solid Brass
PSLT (PrimeShield Lacquer Technology)
Progressive Cartridge Technology
SKU | 14232 |
Weight | 0.9kg |
Brand | ABI Interiors |
Finish/Coating | White – Semi-Gloss PrimeShield Lacquer Technology |
Construction | Solid Brass |
Dimensions (mm) | Handle Diameter: 54mm Backplate Diameter: 62mm |
What's In The Box | In-Wall Kit (required for rough-in): Body + Fixing Screws Locking Nut Ceramic Cartridge Handle Kit (required for fit-off): 1 x Short (15mm) Sleeve 1 x Long (30mm) Sleeve 1 x Dome 1 x Backplate 1 x Handle 1 x Grub Screw 1 x Allen Key |
ETA |
Specification guides can be found under the Downloads tab.
PRODUCT DESCRIPTION | RESIDENTIAL WARRANTY | NON-RESIDENTIAL WARRANTY | OUTDOOR WARRANTY | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Name & Finish | SKU | Structure | Finish | Cartridge | Other | Structure | Finish | Cartridge | Other | Structure | Finish | Cartridge | Other |
Milani Progressive Single Mixer - White | 14232 | 25 | 2 | 7 | 2 | 10 | 1 | 5 | 1 | - | - | - | - |
Product Documents
Milani Progressive Single Mixer - Specification | |
TMV Placement - Specification |
